Handheld Odor Meter
It is critical to assess odor in various situation -odor protection, odor control products as well as fragrance products. OMX series indicates two factors of odor, "STRENGTH", and "CLASSIFICATION" with numeric values.
Features
- Simple and easy to measure odor
- Just turn the switch on
- Data can be stored up to 511 files
- Data logging function with large capacity
- Data can be graphically illustrated by Data filing software
- This product is not CE marked
Handheld Odor Meter OMX-SRM
Handheld Odor Meter OMX-SRM is suitable for detecting odor in lavatories, measuring and sensing smell of cigarettes, medicines, foods and odor from production process.
Real-time Digital Indication
The numeric odor strength level is displayed continuously.
High range and Low range function
High range is from 0 to 999, Low rang is from 0.0 to 99.9. Recommend use Low range for measuring low concentration gas, and High range for measuring high concentration gas.
Odor Classification
A pair of semiconductor gas sensors provides the odor classification.
Handheld Odor Meter OMX-ADM
Handheld Odor Meter OMX-ADM is appropriate for detecting pet odor and putrid smell, checking the effect of deodorization before and after cleaning in hospitals and nursing houses.
Real-time Digital Indication
The numeric odor strength level is displayed continuously.
Odor Intensity
Displayed value is converted into ammonia odor intensity by the scale of 2.5 to 5.0 based on odor concentration of measurement environment.
Handheld Odor Meter OMX-TDM
Handheld Odor Meter OMX-TDM is suitable for detecting TVOC which causes sick house syndrome.
Toluene-value Digital Indication
The value is displayed as toluene concentration value.
Simple setting up in advance
The sampling is user-friendly and collecting data in real time.
Start in short time
Measurement starts quickly in 10min.
- OMX takes odor sampling by using inner pump and shows odor strength level.The strength level is calculated by our original formula using two types of gas sensors that responds to different types of gases.
- OMX detects complex odor and convert it to odor strength level, which means it doesn't classify types of odor.
- The strength level showed in OMX doesn't correlate with human sense of odor.
- OMX does not detect odor well if the gas concentration is not high enough for the device.
Specification
| Model | OMX-SRM | OMX-ADM | OMX-TDM |
|---|---|---|---|
| Detection Method | Two Semiconductor Gas Sensors | ||
| Sampling Method | Continuous Sampling with Built-in Air Pump | ||
| Object Gas |
|
|
|
| Odor Strength Level | 0.0～999 | 0～999 | 0～9999（μg/m3） |
| Classification | Class 0～90 | Odor Intensity 2.5-5.0 | |
| Power | 4×AASize Alkaline Batteries or AC Adaptor *Battery life for continuous measurement is approx. 7 hours. |
||
| Memory Capacity | Up to 32,732 Data | ||
| Memory Partition | Up to 511 Files | ||
| Operating Temperature | 0～40℃ (32-104°F) *No Dew Condensation | ||
| Storage Temperature | -10～50℃ (14-122&drgF) *No Dew Condensation | ||
| Dimensions | W74 X L167.5 X D35mm approx. | ||
| Weight | 250g approx. (Without Batteries) | ||
| Accessories |
|
||
